Factory-Direct Supply of Certified Wires and Conductors for Diverse Industrial Applications
Copper Conductor Quadruplex Service Drop Cable 600V
Voltage: 600V (120/208V three-phase four-wire)
Phase Conductors: 3× soft copper, 7- or 19-strand, PE (75°C) or XLPE (90°C)
Insulation: 45 or 60 mils (1.14 or 1.52mm)
Neutral Messenger: Bare hard-drawn copper, solid or 7-strand
Application: 3-phase overhead service drops for multi-family & commercial
Ampacity: 75-350A PE / 95-350A XLPE (6 AWG to 4/0 AWG)
Package: Export wooden reel or coil
Product Overview
Copper Conductor Quadruplex Service Drop Cable 600V is a neutral-supported overhead service cable with three phase conductors and one bare neutral messenger, assembled in a quadruplex (four-conductor twisted) configuration. Phase conductors: concentrically stranded compressed soft copper, insulated with PE (75°C) or XLPE (90°C). Neutral: bare hard-drawn copper, solid or stranded. The quadruplex configuration provides three 120V phase legs plus a grounded neutral for 120/208V three-phase wye service — the standard for multi-family residential buildings, small commercial services, and light industrial applications requiring three-phase power from an overhead drop.
Service Drop Cable Comparison
| Duplex | Triplex | Quadruplex | |
|---|---|---|---|
| Conductors | 1 phase + neutral | 2 phase + neutral | 3 phase + neutral |
| System | 120V 2-wire | 120/240V 3-wire | 120/208V 3-phase 4-wire |
| Typical Use | Small loads, lighting | Standard residential | Multi-family, commercial, 3-phase |
Phase Conductors (×3)
Concentrically stranded compressed soft copper per ASTM B-8. PE (75°C) or XLPE (90°C). 45 or 60 mils insulation.
Neutral Messenger
Bare hard-drawn copper, solid or 7-strand per ASTM B-1. Supports full mechanical tension of the overhead span.
Quadruplex Assembly
Three insulated phases twisted around the bare neutral. Single-cable overhead drop for complete 3-phase service entrance.
Applicable Standards
| Standard | Scope |
|---|---|
| ASTM B-1 | Hard-drawn copper wire for bare neutral messenger. |
| ASTM B-3 | Soft/annealed copper wire for phase conductor flexibility. |
| ASTM B-8 | Concentric-lay-stranded copper conductors. |
| ANSI/ICEA S-76-474 | Primary standard for neutral-supported power cable assemblies rated 600V. |
Technical Specifications — Copper Quadruplex Service Drop
Phase: concentrically stranded compressed soft copper. Neutral: bare hard-drawn copper. Weights in lbs/1000ft. Multiply ×1.488 for kg/km.
| Code Word | Phase (AWG) | Phase Stranding | Insul. (mils) | Neutral (AWG) | Neutral Stranding | Neutral Str (lbs) | Wt PE (lbs/1000ft) | Wt XLPE (lbs/1000ft) | Amp PE | Amp XLPE |
|---|---|---|---|---|---|---|---|---|---|---|
| Atlanta | 6 | 7 | 45 | 6 | Solid | 1,280 | 368 | 374 | 75 | 95 |
| Tallahassee | 6 | 7 | 45 | 6 | 7 | 1,228 | 369 | 376 | 75 | 95 |
| Richmond | 4 | 7 | 45 | 4 | 7 | 1,938 | 573 | 581 | 100 | 125 |
| Baton Rouge | 4 | 7 | 45 | 4 | Solid | 1,970 | 570 | 578 | 100 | 125 |
| Jackson | 2 | 7 | 45 | 2 | Solid | 3,003 | 889 | 889 | 135 | 170 |
| Seattle | 2 | 7 | 45 | 2 | 7 | 3,050 | 893 | 893 | 135 | 170 |
| Nashville | 1/0 | 19 | 60 | 1/0 | 7 | 4,752 | 1,420 | 1,457 | 180 | 230 |
| Lincoln | 2/0 | 19 | 60 | 2/0 | 7 | 5,926 | 1,773 | 1,773 | 205 | 265 |
| Raleigh | 3/0 | 19 | 60 | 3/0 | 7 | 7,366 | 2,220 | 2,220 | 235 | 305 |
| Denver | 4/0 | 19 | 60 | 4/0 | 7 | 9,154 | 2,781 | 2,803 | 270 | 350 |
Packaging & Delivery
Export Wooden Reel
Plywood or wooden reels. Quadruplex cable heavier than triplex — standard utility reel sizes.
Coil Packaging
Smaller AWG sizes available in coils. Utility-standard packaging for service truck deployment.
Documentation
ASTM B-1/B-3/B-8 mill certificates, messenger tensile test per ICEA S-76-474.
Typical Applications — Copper Quadruplex Service Drop
Multi-Family & Apartment Buildings
Primary application. 120/208V 3-phase service to apartment buildings, condominiums, and multi-family complexes requiring 3-phase distribution.
Small Commercial Services
3-phase overhead service to restaurants, retail stores, workshops, and small office buildings with 208V equipment.
Light Industrial
Small manufacturing units, auto repair shops, and warehouses with 3-phase motor loads (HVAC, compressors, lifts).
Commercial Lighting
3-phase service for large parking lot lighting arrays, sports field lighting, and exterior commercial area illumination.
Service Upgrades
Upgrade from single-phase triplex to 3-phase quadruplex for expanding commercial and multi-family electrical loads.
Temporary Construction
3-phase temporary power for construction sites with 208V equipment. Quick overhead deployment and removal.
