Power Cable

NA2XBY Cable

0.6/1kV NA2XBY XLPE Insulated Steel Tape Armoured PVC Sheathed Aluminium Power Cable

Voltage: 600/1000V (0.6/1kV)
Conductor: Aluminium, Class 2 stranded, IEC 60228
Insulation: XLPE, rated 90°C, VDE 0276-603 colour coded
Armour: Double galvanized steel tape (0.2/0.5mm)
Sheath: Black PVC, flame retardant, UV resistant
Number of cores: 2-5 cores, 3G/4G earth, 3+1/4+1 reduced
Standard: DIN VDE 0276-603 (primary), IEC 60502-1, HD 308 S2

Product Overview

NA2XBY Cable is a 0.6/1kV XLPE-insulated steel tape armoured PVC-sheathed power cable with aluminium conductor, manufactured to IEC 60502-1. Naming follows VDE convention: N = standard type, A = aluminium conductor, 2X = XLPE insulation, B = steel tape armour (Bewehrung), Y = PVC outer sheath. It is the 90°C XLPE upgrade of NAYBY (70°C PVC) — same Al/STA/PVC construction with XLPE's higher thermal rating (90°C continuous, 250°C short-circuit vs 70°C/160°C for PVC). NA2XBY is the aluminium counterpart of N2XBY (copper conductor), offering significant weight and cost savings for projects where aluminium conductor economics are preferred. Single-core variants use non-magnetic steel tape (aluminium tape) to prevent eddy current heating.

NA2XBY Cable Cross Section with 3D Cutaway and 2D Cross-Section

Outer Sheath — Black PVC, flame retardant
Steel Tape Armour — Double galvanized, helically applied
PVC Bedding — Light blue-grey extruded separation sheath
XLPE Insulation — 90°C, VDE 0276-603 colour coded
Aluminium Conductor — Class 2 stranded per IEC 60228

Aluminium Conductor

Class 1 (solid) or Class 2 (stranded) per IEC 60228. 61% IACS at ~50% weight of equivalent copper. Solid for ≤4mm².

XLPE Insulation

90°C continuous, 250°C short-circuit (max 5s). Test voltage 4kV. VDE 0276-603 colour coded: Brown/Black/Grey/Blue + Green/Yellow.

PVC Bedding

Light blue-grey extruded separation sheath between cores and armour. Protects XLPE from steel tape abrasion during bending.

Steel Tape Armour

Double galvanized steel tape. Non-magnetic (aluminium tape) for single-core to prevent eddy currents. 0.2mm for ≤35mm², 0.5mm for ≥50mm².

PVC Outer Sheath

Black PVC, flame retardant per IEC 60332-1. UV resistant for outdoor installation. Moisture-proof for underground use.

XLPE Over PVC Upgrade

90°C vs 70°C continuous rating. Higher ampacity, better overload and short-circuit tolerance (250°C vs 160°C) compared to NAYBY.

Technical Characteristics

Rated Voltage Uo/U (Um)	0.6/1 (1.2) kV
Nominal Voltage DC (core-earth/core-core)	1.8/1.8 kV
Test Voltage	4 kV
Max. Conductor Temperature	90°C (continuous), 250°C (short-circuit, max 5s)
Temperature Rating (Flexed)	+5°C to +90°C
Temperature Rating (Fixed)	-35°C to +90°C
Min. Bending Radius	15 × D (single-core), 12 × D (multi-core)
Flame Performance	IEC 60332-1 (single cable vertical flame test)

Applicable Standards

Standard	Scope
IEC 60502-1	Power cables with extruded insulation for rated voltages 1kV (Um=1.2kV) up to 30kV. Primary standard covering NA2XBY construction and testing.
IEC 60228	Conductors of insulated cables. Class 1 solid and Class 2 stranded aluminium conductors.
IEC 60332-1	Single cable vertical flame test. Mandatory for building installation cables in EU.
HD 308 S2	Harmonised European core identification standard. Applied for EU cross-border projects.
DIN VDE 0276-603	German national standard referenced alongside IEC 60502-1 for VDE-compliant installations.

Core Identification (HD 308 S2 / VDE 0276-603)

Configuration	Core Colours
1 x	Black
2 x	Blue + Brown
3 G	Green/Yellow + Blue + Brown
3 x	Brown + Black + Grey
4 G	Green/Yellow + Brown + Black + Grey
4 x	Blue + Brown + Black + Grey
5 G	Green/Yellow + Blue + Brown + Black + Grey
3 x + 1 x	Brown + Black + Grey + Blue (reduced neutral)
3 x + 2 x	Brown + Black + Grey + Blue + Green/Yellow (reduced neutral + reduced earth)
4 x + 1 x	Brown + Black + Grey + Blue + Green/Yellow (reduced earth)

NA2XBY vs NAYBY — when to upgrade: Choose NA2XBY (XLPE 90°C) over NAYBY (PVC 70°C) when the installation requires higher ampacity per cross-section or overload tolerance. The XLPE short-circuit rating (250°C vs 160°C) provides an extra safety margin in industrial networks. Note: NA2XBY multi-core bending radius is 12×D — same as NAYBY, not tighter. For single-core, NA2XBY requires 15×D vs 12×D for NAYBY. For projects with strict budget constraints and standard indoor routing, NAYBY remains cost-effective.

Technical Specifications

Aluminium conductor, XLPE insulated, steel tape armoured, PVC sheathed per IEC 60502-1. Non-magnetic (aluminium) tape for single-core. DC resistance per IEC 60228 Class 2 aluminium at 20°C. Armour: 0.2mm (≤35mm²), 0.5mm (≥50mm²). Ampacity at 30°C ambient air / 20°C ground temperature.

1-Core NA2XBY Cable (Non-Magnetic Armour)

Cross Section (mm²)	Insul. (mm)	Armour (mm)	Sheath (mm)	O.D. (mm)	Weight (kg/km)	20°C Res. (Ω/km)	Air (A)	Ground (A)
1 × 10	0.7	0.2	1.8	11.8	206	3.08	58	47
1 × 16	0.7	0.2	1.8	12.9	247	1.91	75	62
1 × 25	0.9	0.2	1.8	14.6	310	1.20	100	78
1 × 35	0.9	0.2	1.8	15.2	352	0.868	120	94
1 × 50	1.0	0.2	1.8	16.7	423	0.641	145	110
1 × 70	1.1	0.2	1.8	18.5	523	0.443	190	135
1 × 95	1.1	0.2	1.8	20.1	629	0.320	235	160
1 × 120	1.2	0.2	1.8	21.7	738	0.253	270	185
1 × 150	1.4	0.2	1.8	23.7	877	0.206	310	205
1 × 185	1.6	0.2	1.8	25.7	1,031	0.164	355	235
1 × 240	1.7	0.2	1.8	28.0	1,254	0.125	—	—
1 × 300	1.8	0.2	1.9	31.0	1,495	0.100	—	—
1 × 400	2.0	0.2	2.0	35.0	1,904	0.0778	—	—

2-Core NA2XBY Cable

Cross Section (mm²)	Insul. (mm)	Armour (mm)	Sheath (mm)	O.D. (mm)	Weight (kg/km)	20°C Res. (Ω/km)	Air (A)	Ground (A)
2 × 2.5	0.7	0.2	1.8	13.4	236	12.1	—	23
2 × 4	0.7	0.2	1.8	14.3	269	7.41	—	30
2 × 6	0.7	0.2	1.8	15.3	307	4.61	—	38
2 × 10	0.7	0.2	1.8	17.8	397	3.08	50	47
2 × 16	0.7	0.2	1.8	20.0	493	1.91	64	62
2 × 25	0.9	0.2	1.8	23.3	643	1.20	86	78
2 × 35	0.9	0.2	1.8	24.6	738	0.868	105	94
2 × 50	1.0	0.2	1.8	27.2	896	0.641	125	110
2 × 70	1.1	0.2	1.9	31.4	1,164	0.443	165	135
2 × 95	1.1	0.2	2.0	35.5	1,480	0.320	200	160
2 × 120	1.2	0.5	2.2	40.2	2,164	0.253	235	185
2 × 150	1.4	0.5	2.3	44.2	2,572	0.206	270	205
2 × 185	1.6	0.5	2.5	48.9	3,089	0.164	310	235

3-Core NA2XBY Cable

Cross Section (mm²)	Insul. (mm)	Armour (mm)	Sheath (mm)	O.D. (mm)	Weight (kg/km)	20°C Res. (Ω/km)	Air (A)	Ground (A)
3 × 2.5	0.7	0.2	1.8	13.9	257	12.1	—	23
3 × 4	0.7	0.2	1.8	14.8	296	7.41	—	30
3 × 6	0.7	0.2	1.8	16.0	342	4.61	—	38
3 × 10	0.7	0.2	1.8	18.6	447	3.08	50	47
3 × 16	0.9	0.2	1.8	21.0	563	1.91	64	62
3 × 25	0.9	0.2	1.8	24.6	744	1.20	86	78
3 × 35	0.9	0.2	1.8	26.0	869	0.868	105	94
3 × 50	1.0	0.2	1.9	28.9	1,074	0.641	125	110
3 × 70	1.1	0.2	2.0	33.9	1,443	0.443	165	135
3 × 95	1.1	0.5	2.2	39.0	2,183	0.320	200	160
3 × 120	1.2	0.5	2.3	42.7	2,593	0.253	235	185
3 × 150	1.4	0.5	2.4	47.5	3,155	0.206	270	205
3 × 185	1.6	0.5	2.6	52.1	3,743	0.164	310	235
3 × 240	1.7	0.5	2.8	58.3	4,641	0.125	365	260
3 × 300	1.8	0.5	2.9	63.6	5,508	0.100	420	290

4-Core NA2XBY Cable

Cross Section (mm²)	Insul. (mm)	Armour (mm)	Sheath (mm)	O.D. (mm)	Weight (kg/km)	20°C Res. (Ω/km)	Air (A)	Ground (A)
4 × 2.5	0.7	0.2	1.8	14.7	288	12.1	—	23
4 × 4	0.7	0.2	1.8	15.8	334	7.41	—	30
4 × 6	0.7	0.2	1.8	17.0	384	4.61	—	38
4 × 10	0.7	0.2	1.8	20.0	509	3.08	50	47
4 × 16	0.9	0.2	1.8	22.7	649	1.91	64	62
4 × 25	0.9	0.2	1.8	26.7	880	1.20	86	78
4 × 35	0.9	0.2	1.8	28.3	1,040	0.868	105	94
4 × 50	1.0	0.2	2.1	32.0	1,365	0.641	125	110
4 × 70	1.1	0.5	2.1	38.5	2,138	0.443	165	135
4 × 95	1.1	0.5	2.3	42.9	2,638	0.320	200	160
4 × 120	1.2	0.5	2.4	47.4	3,202	0.253	235	185
4 × 150	1.4	0.5	2.6	52.3	3,847	0.206	270	205
4 × 185	1.6	0.5	2.7	57.5	4,585	0.164	310	235
4 × 240	1.7	0.5	3.0	64.3	5,709	0.125	365	260
4 × 300	1.8	0.5	3.1	70.3	6,805	0.100	420	290

5-Core NA2XBY Cable

Cross Section (mm²)	Insul. (mm)	Armour (mm)	Sheath (mm)	O.D. (mm)	Weight (kg/km)	20°C Res. (Ω/km)	Air (A)	Ground (A)
5 × 2.5	0.7	0.2	1.8	15.6	321	12.1	—	23
5 × 4	0.7	0.2	1.8	16.8	376	7.41	—	30
5 × 6	0.7	0.2	1.8	18.2	443	4.61	—	38
5 × 10	0.7	0.2	1.8	21.6	592	3.08	50	47
5 × 16	0.7	0.2	1.8	24.6	763	1.91	64	62
5 × 25	0.9	0.2	1.8	29.0	1,029	1.20	86	78
5 × 35	0.9	0.2	1.9	31.0	1,236	0.868	105	94
5 × 50	1.0	0.2	2.1	35.7	1,616	0.641	125	110
5 × 70	1.1	0.5	2.3	42.4	2,528	0.443	165	135
5 × 95	1.1	0.5	2.4	47.2	3,172	0.320	200	160
5 × 120	1.2	0.5	2.6	51.8	3,801	0.253	235	185
5 × 150	1.4	0.5	2.7	57.6	4,604	0.206	270	205
5 × 185	1.6	0.5	2.9	63.8	5,574	0.164	310	235
5 × 240	1.7	0.5	3.2	70.7	6,859	0.125	365	260
5 × 300	1.8	0.5	3.4	78.0	8,305	0.100	420	290

Reduced Neutral/Earth Configurations

Cross Section (mm²)	Insul. (mm)	Armour (mm)	Sheath (mm)	O.D. (mm)	Weight (kg/km)	20°C Res. (Ω/km)	Air (A)	Ground (A)
3+1 Core
3 × 4 + 1 × 2.5	0.7/0.7	0.2	1.8	15.5	318	7.41/12.1	—	30
3 × 6 + 1 × 4	0.7/0.7	0.2	1.8	16.8	371	4.61/7.41	—	38
3 × 10 + 1 × 6	0.7/0.7	0.2	1.8	19.3	478	3.08/4.61	50	47
3 × 16 + 1 × 10	0.7/0.7	0.2	1.8	22.1	615	1.91/3.08	64	62
3 × 25 + 1 × 16	0.9/0.7	0.2	1.8	25.1	794	1.20/1.91	86	78
3 × 35 + 1 × 16	0.9/0.7	0.2	1.8	26.8	926	0.868/1.91	105	94
3 × 50 + 1 × 25	1.0/0.9	0.2	1.9	30.2	1,175	0.641/1.20	125	110
3 × 70 + 1 × 35	1.1/0.9	0.2	2.0	35.1	1,570	0.443/0.868	165	135
3 × 95 + 1 × 50	1.1/1.0	0.5	2.2	40.4	2,359	0.320/0.641	200	160
3 × 120 + 1 × 70	1.2/1.1	0.5	2.3	45.0	2,886	0.253/0.443	235	185
3 × 150 + 1 × 70	1.4/1.1	0.5	2.5	49.1	3,396	0.206/0.443	270	205
3 × 185 + 1 × 95	1.6/1.1	0.5	2.8	54.3	4,070	0.164/0.320	310	235
3 × 240 + 1 × 120	1.7/1.2	0.5	2.8	59.1	4,855	0.125/0.253	365	260
3 × 300 + 1 × 150	1.8/1.4	0.5	3.0	66.0	6,028	0.100/0.206	420	290
4+1 Core
4 × 4 + 1 × 2.5	0.7/0.7	0.2	1.8	16.3	365	7.41/12.1	—	30
4 × 6 + 1 × 4	0.7/0.7	0.2	1.8	17.7	429	4.61/7.41	—	38
4 × 10 + 1 × 6	0.7/0.7	0.2	1.8	20.3	561	3.08/4.61	50	47
4 × 16 + 1 × 10	0.7/0.7	0.2	1.8	24.0	728	1.91/3.08	64	62
4 × 25 + 1 × 16	0.9/0.7	0.2	1.8	28.1	974	1.20/1.91	86	78
4 × 35 + 1 × 16	0.9/0.7	0.2	1.9	29.6	1,134	0.868/1.91	105	94
4 × 50 + 1 × 25	1.0/0.9	0.2	2.0	34.0	1,505	0.641/1.20	125	110
4 × 70 + 1 × 35	1.1/0.9	0.5	2.2	40.3	2,351	0.443/0.868	165	135
4 × 95 + 1 × 50	1.1/1.0	0.5	2.3	44.8	2,907	0.320/0.641	200	160
4 × 120 + 1 × 70	1.2/1.1	0.5	2.6	50.2	3,588	0.253/0.443	235	185
4 × 150 + 1 × 70	1.4/1.1	0.5	2.8	54.6	4,215	0.206/0.443	270	205
4 × 185 + 1 × 95	1.6/1.1	0.5	2.9	60.5	5,133	0.164/0.320	310	235
4 × 240 + 1 × 120	1.7/1.2	0.5	3.0	67.1	6,289	0.125/0.253	365	260
4 × 300 + 1 × 150	1.8/1.4	0.5	3.2	73.7	7,544	0.100/0.206	420	290
3+2 Core
3 × 4 + 2 × 2.5	0.7/0.7	0.2	1.8	16.6	354	7.41/12.1	—	30
3 × 6 + 2 × 4	0.7/0.7	0.2	1.8	18.0	416	4.61/7.41	—	38
3 × 10 + 2 × 6	0.7/0.7	0.2	1.8	20.9	531	3.08/4.61	50	47
3 × 16 + 2 × 10	0.7/0.7	0.2	1.8	24.0	694	1.91/3.08	64	62
3 × 25 + 2 × 16	0.9/0.7	0.2	1.8	28.1	920	1.20/1.91	86	78
3 × 35 + 2 × 16	0.9/0.7	0.2	1.9	29.6	1,034	0.868/1.91	105	94
3 × 50 + 2 × 25	1.0/0.9	0.2	2.0	34.0	1,400	0.641/1.20	125	110
3 × 70 + 2 × 35	1.1/0.9	0.5	2.2	40.3	2,153	0.443/0.868	165	135
3 × 95 + 2 × 50	1.1/1.0	0.5	2.3	44.8	2,658	0.320/0.641	200	160
3 × 120 + 2 × 70	1.2/1.1	0.5	2.5	50.2	3,329	0.253/0.443	235	185
3 × 150 + 2 × 70	1.4/1.1	0.5	2.6	54.6	3,790	0.206/0.443	270	205
3 × 185 + 2 × 95	1.6/1.1	0.5	2.8	60.5	4,575	0.164/0.320	310	235
3 × 240 + 2 × 120	1.7/1.2	0.5	3.0	67.1	5,564	0.125/0.253	365	260
3 × 300 + 2 × 150	1.8/1.4	0.5	3.2	73.7	6,801	0.100/0.206	420	290

Packaging & Delivery

Parameter	Standard
Drum Type	Wooden drum / iron-wooden drum / corrugated box (small sizes)
Length per Drum	500m / 1000m (standard); custom lengths available
Drum Marking	Manufacturer, cable type, voltage, cross-section, length, weight, drum number, production date
Cable End Sealing	Heat-shrink end caps to prevent moisture ingress during transport and storage
Outer Protection	Weatherproof wrapping with desiccant for sea freight
Delivery Condition	Factory-new, tested per IEC 60502-1, with test certificate on request

Typical Applications

Underground Distribution

Direct burial in soil for LV power networks. Steel tape armour + XLPE insulation provide the highest reliability for permanent underground installation.

Industrial Feeders

Power supply to high-load motors, transformers, and production lines. 90°C XLPE handles overload conditions that 70°C PVC cannot.

Building Main Supply

Main distribution cables in commercial and residential buildings. 12×D bending radius for multi-core routing through conduits and cable trays.

Solar Farm LV Collection

LV collector circuits in photovoltaic farms. Aluminium conductor economics favour long cable runs; XLPE handles elevated ambient temperatures.

Cable Trays & Trenches

Open-air installation on cable trays or covered trenches. UV-resistant black PVC sheath for outdoor routing between buildings and substations.

Infrastructure Projects

Water treatment, pumping stations, tunnel lighting, and rail infrastructure requiring IEC 60502-1 certified XLPE armoured cable.

NA2XBY vs N2XBY — cost vs performance: NA2XBY uses aluminium conductor with identical XLPE insulation and steel tape armour as N2XBY (copper). Aluminium DC resistance is ~1.68× copper at the same cross-section (IEC 60228). For projects where aluminium conductor economics are acceptable, NA2XBY delivers IEC-certified XLPE performance at substantially lower material cost. Single-core requires non-magnetic (aluminium) tape armour; multi-core uses galvanized steel tape. For maximum conductivity per cross-section, specify N2XBY (copper).
